| Model: | 12000LB-S12000 |
|---|---|
| Min. Order: | 100 Piece/Pieces |
| Payment Terms: | Paypal, L/C, T/T, WU |
| Place of Origin: | Zhejiang, China (Mainland) |
| Production Capacity: | Annual output 40000PCS |
| Packing: | carton |
| Delivery Date: | about 25 days |
| Specification: | 12V/24V | Function: | vehicle recovery |
|---|---|---|---|
| Certificate: | CE, FCC, ISO9001:2008 | Export Area: | Europe,US,Australia |
12000LB FEATURES AND SPECIFICATIONS | |
Rated line pull | 12000LB (5443 KG) single line |
Motor | 5.5hp/4.0kw (12V);5.98hp/4.46kw(24V) |
Control | Remote switch,12ft(3.7m)lead |
Gear train | 3 Stage Planetary |
Gear reduction ratio | 187.2:1 |
Clutch | Sliding Ring Gear |
Braking Action | Automatic In-The-Drum |
Drum Size | Φ64x224mm |
Cable | 3/8" of 94ft diameter (Φ9.4mmx28m) |
Fairlead | 4-Way Roller Fairlead |
Remote Control | Included |
Battery | Recommended:650CCA minimum for winching |
Battery Leads | 2 gauge,72"(183mm) |
Finish | Dark gray powder coat |
Overall Dimensions | 21.1"x6.3"x9.5"(537mmx160mmx280mm) |
Mounting Bolt Pattern | 254mmx114.3mm |
Weight | N.W. 40kg G.W.43kg |
Packing size | 57x19x34.5cm 1PC/CTN |
12000LB LINE SPEED AND AMP DRAW (FIRST LAYER) 12V | ||||||||
Line Pull | lb | NO LOAD | 2000 | 4000 | 6000 | 8000 | 10000 | 10000 |
kg | 907 | 1814 | 27221 | 3629 | 4532 | 5443 | ||
Line Speed | ft/min | 21.3 | 11.5 | 9.4 | 7.9 | 6.5 | 5.8 | 4.4 |
m/min | 6.5 | 3.1 | 2.85 | 2.4 | 2 | 1.75 | 1.35 | |
Motor | Amps | 65 | 126 | 175 | 230 | 280 | 355 | 400 |
12000LB LINE SPEED AND AMP DRAW (FIRST LAYER) 24V | ||||||||
Line Pull | lb | 0 | 2000 | 4000 | 6000 | 8000 | 10000 | 12000 |
kg | 0 | 907 | 1814 | 2721 | 3628 | 4536 | 5443 | |
Line Speed | ft/min | 25.22 | 12.6 | 9.91 | 8.23 | 7.02 | 6.13 | 4.85 |
m/min | 7.69 | 3.84 | 3.02 | 2.51 | 2.14 | 1.87 | 1.48 | |
Motor | Amps | 50 | 102 | 142 | 171 | 198 | 230 | 298 |
12000LB LINE PULL AND CABLE CAPACITY | |||||
Layers of cable | 1 | 2 | 3 | 4 | |
Rated Line Pull Per Layer | lb | 12000 | 9210 | 8030 | 6894 |
kg | 5443 | 4178 | 3642 | 3127 | |
Cumulative cable capacity | ft | 18 | 39 | 64 | 92 |
m | 5.5 | 11.8 | 19.5 | 28 | |
