| Model: | P4000-1D(12V) |
|---|---|
| Min. Order: | 50 Piece/Pieces |
| Payment Terms: | Paypal, L/C, T/T, WU |
| Place of Origin: | Zhejiang, China (Mainland) |
| Means of Transport: | Ocean, Air |
| Production Capacity: | Annual output 60000PCs |
| Packing: | corrugated carton |
| Delivery Date: | about 25 days | steel material: | cable or synthetic rope |
|---|---|---|---|
| electric power: | atv winch | CE, FCC, ISO9001: | permanent magnetic motor |
| Capacity: | 4000lbs | Approval: | CE |
| Insurance: | Product Liability INsurance |
Motor: 0.9KW/1.24HP, 12V, Permanent magnet
Gear reduction ration: 128.2:1
Geartarain: 3-Stage Planetary
Clutch (free spooling): cam activated
Drum dimensions: Φ13.9"×4.6"×4.92"(353mm×117mm×125mm)
Cable (Dia×L): Φ1/4"×44.3' (Φ6.0mm×13.5m)
Packing size: 41.5×28×18cm, 1PC/CTN
Weight: N.W./G.W.: 13kg/14kg
Line Speed and AMP Draw (First Layer) 12V
Line Pull | Lb | NO | 500 | 1000 | 1500 | 2000 | 2500 | 3000 | 4000 |
kg | LOAD | 227 | 454 | 680 | 907 | 1133 | 1361 | 1814 | |
Line Speed | ft/min | 23.7 | 23.1 | 20.6 | 2.47 | 13.4 | 10.7 | 8.5 | 6.79 |
m/min | 6.7 | 5.95 | 5.3 | 0.75 | 3.45 | 2.75 | 2.2 | 1.75 | |
Motor | Amps | 26 | 35 | 70 | 42 | 107 | 129 | 138 | 205 |
Line pull and cable capacity
layers of cable | 1 | 2 | 3 | 4 | 5 | |
rated line pull per layer | lb | 4000 | 2817 | 2573 | 2363 | 1975 |
kg | 1814 | 1278 | 1167 | 1072 | 896 | |
