| Model: | SIC12000W |
|---|---|
| Min. Order: | 100 Piece/Pieces |
| Payment Terms: | Paypal, L/C, T/T, WU |
| Place of Origin: | Zhejiang, China (Mainland) |
| Means of Transport: | Ocean, Air, Land |
| Production Capacity: | Annual output 40000PCS |
| Packing: | carton, pallet |
| Delivery Date: | about 25 days | Power supply: | DC 12V/24V |
|---|---|---|---|
| Capacity: | 12000lbs | winch body: | sealed |
| soloenoid: | 500a waterproof | Function: | self-recovery |
| Certificate: | CE,FCC,ISO9001:2008 | Export Area: | Europe,US,Australia |
| Rope: | 10mmx28m |
12000LB FEATURES AND SPECIFICATIONS | |
Rated line pull | 12000LB (5443 KG) single line |
Motor | 6.6hp/4.8kw (12V);4.0hp/3.0kw(24V) |
Control | Remote switch,12ft(3.7m)lead |
Gear train | 3 Stage Planetary |
Gear reduction ratio | 187.2:1 |
Braking Action | Automatic In-The-Drum |
Cable | 3/8" of 94ft diameter (Φ9.4mmx28m) |
Main body | sealed |
Fairlead | 4-Way Roller Fairlead |
Wireless Remote Control | Optional |
Battery | Recommended:650CCA minimum for winching |
Battery Leads | 2 gauge,72"(183mm) |
Finish | Dark gray powder coat |
Overall Dimensions | 21.1"x6.3"x8.6"(537mmx160mmx218mm) |
Mounting Bolt Pattern | 254mmx114.3mm |
Weight | N.W. 40kg G.W.43kg |
Packing size | 57x19x34.5cm 1PC/CTN |
12000LB LINE PULL AND CABLE CAPACITY | |||||
Layers of cable | 1 | 2 | 3 | 4 | |
Rated Line Pull Per Layer | lb | 12000 | 9210 | 8030 | 6894 |
kg | 5443 | 4170 | 3640 | 3125 | |
Cumulative cable capacity | ft | 17 | 41 | 71 | 82 |
m | 4.8 | 12 | 21 | 25 | |
12000LB LINE SPEED AND AMP DRAW (FIRST LAYER) 12V | ||||||||
Line Pull | lb | 0 | 4000 | 6000 | 8000 | 10000 | 12000 | 12300 |
kg | 0 | 1810 | 2720 | 3630 | 4540 | 5440 | 5590 | |
Line Speed | ft/min | 33.3 | 16.8 | 12.8 | 10.1 | 8.8 | 7.6 | 0 |
m/min | 10.3 | 5.1 | 3.9 | 3.1 | 2.7 | 2.3 | 0 | |
Motor | Amps | 85 | 158 | 231 | 3.2 | 371 | 450 | 200 |
12000LB LINE SPEED AND AMP DRAW (FIRST LAYER) 24V | ||||||||
Line Pull | lb | 0 | 4000 | 6000 | 8000 | 10000 | 12000 | 12300 |
kg | 0 | 1810 | 2720 | 3630 | 4540 | 5440 | 5590 | |
Line Speed | ft/min | 35 | 18.5 | 14.4 | 11.5 | 10 | 8.9 | 0 |
m/min | 10.8 | 5.6 | 4.4 | 3.5 | 3.1 | 2.7 | 0 | |
Motor | Amps | 50 | 136 | 170 | 210 | 240 | 280 | 100 |
